My primary reason for using Cucumber in a recent automation initiative was to try and bridge a technology-business divide that existed in my workplace by giving the non-technical stakeholders a larger sense of involvement in testing with a (longer term) view to them actively contributing to future test specs by using the plain English approach that Cucumber does so well.
However, when I first started looking into Cucumber, there were a multitude of references out there but as I was also learning about Ruby, Watir and RSpec at the same time it became a little difficult to see the wood for the trees because they tended to talk about all of these things without being clear about where one thing stopped and another began.
What I’d like to do with this post is present a simple Cucumber 101 tutorial, letting cucumber guide us through the creation of a set of ‘scenarios’ (this is what Cucumber calls ‘tests’ or to be more precise, ‘checks’ – this is automated after all).
1. Cucumber Basics
Cucumber is a command line tool and when you run it, it looks for plain-language text files which typically contain one or more features, and within each feature, one or more scenarios to test. Within each scenario you have a number of steps that Cucumber works through. There is some syntax involved so that cucumber can understand what you’ve written and this is known as Gherkin. I’ll highlight this in the examples below.
So if you were to see the directory structure required for a simple cucumber project, it would look something like this:
2. Installation Prerequisites
This tutorial assumes you have a copy of ruby, rubygems (or equivalent), watir-webdriver, rspec and of course cucumber installed on your target system.
3. Create a Scenario
Let’s create a new Cucumber project (a directory, called ‘Cuke’) and try running cucumber in this empty directory.
Wait, how do we run cucumber? Simple, type ‘cucumber’ (Note: We can specify arguments but in the absence of any cucumber assumes you want to run everything – more on that later).
So we have no features or scenarios. Cucumber is looking for a features directory. Let’s create one as it suggests. Once we’ve done that, let’s try running cucumber again.
So now we see that although cucumber found a features directory, there were no feature files and consequently no scenarios to run, hence the “0 scenarios” and “0 steps” references.
Let’s create a scenario in a feature file under the features directory, and let’s call the feature file karate.feature. Here’s the content:
For those of you unfamiliar with karate, Hironori Ohtsuka was the founder of the Wado-Ryu style of karate, and our scenario is checking for the presence of the founder’s surname in the Google results on a search for ‘Wado’.
You can see the Gherkin grammar highlighted in blue above – these must be used when writing feature files – the key Gherkin words include – Feature, Background, Scenario, Scenario Outline, Scenarios (or Examples), Given, When, Then, And (or But) and a couple of other symbols.
Now let’s run cucumber again with the new feature file in place:
So, cucumber is now picking up our new feature file. Great!
However, all of our scenario steps are as yet undefined.
4. Add Step Definitions
So, two things about the above output. Cucumber is telling us that our steps and scenario are as yet undefined (the yellow text) and that as yet, it doesn’t know which programming language we intend to use to implement our scenarios (the red text). Let’s take our lead from Cucumber and copy the suggested steps into a new step definition file, say step_karate.rb (The .rb suffix indicates a Ruby file). Like so…
and run cucumber again
You may notice that the red text we saw in the ‘undefined’ error above has now gone. Why? We’ve put a Ruby (.rb) step definition file in place so Cucumber now knows we’re intending to use ruby to implement the scenario. So now we can map all the steps in our scenario to a step definition file, and cucumber helpfully provides the file and line number of each step it finds (this comes in useful later when you have large suites of scenarios) You’ll also notice that Cucumber has deemed the first step as ‘pending‘ (I.e. to be implemented) – this is due to the pending statement in the step definition. This acts as a placeholder so you can write some proper code for each step when you are ready. Cucumber takes a sequential approach to scenario steps and the subsequent steps are deemed ‘skipped‘
5. Implement Step Definitions
Let’s implement our first step definition now. We’ll take out the pending statement and put in some Ruby code that will start a web-browser.
So for our first step “I navigate to Google” we’ve removed the pending statement and inserted two lines of Ruby/Watir-Webdriver, to start a browser (Firefox) and to navigate to Google.
Note: I’ve included a Ruby ‘require’ statement in the step definition file. There are tidier ways of doing this since the key to maintainability of any cucumber suite lies with the step definition files. We’ll tidy this up a bit later
Let’s run cucumber again
Now we see the first step passes (green), the second step is pending (yellow), and the third step is skipped (blue). Progress! You’ll also notice a browser opened in front of you (at Google) that hasn’t been closed – that’s because we didn’t close it in our code (yet). For now, kill the browser – we’ll tidy that up later. Let’s implement the remaining steps as shown below:
In the second step, we create variables for the Google search field and button, then enter the value ‘Wado’ into the search field and click on the button. In the third step we check that the results page has loaded and then perform another check to see if the text ‘Ohtsuka’ is present in the results page. If it’s there, the step will pass, and if it’s not the step will fail. Lastly, we close the browser instance.
6. Passed & Failed Scenarios
So, if we run cucumber once again with all our implemented steps:
Whoa! 3 passed steps and 1 passed scenario. Nice!
However, in order to see what a failed scenario looks like, let’s deliberately alter the string literal in the last step ‘Ohtsuka’ to ‘Octavias’ as we don’t expect that to appear in the page, and run cucumber again:
So you can see from the above the scenario has now failed after being unable to locate ‘Octavias’ in the results page. If you run this you’ll notice that the browser stayed open which means the @browser.close statement was never executed. Hmm, messy. Let’s tidy this up a bit…
7. Tidy Up – Environment, Hooks, etc
First of all, let’s get rid of that ‘require’ statement in the step definition file and put it somewhere more appropriate. We’ll create a new directory under features, called support, and under there we’ll create an environment file, env.rb and add two lines
The first line extends the path that Cucumber picks up to include a Cuke/lib (we haven’t created that yet)
The second line includes a Ruby file called myClasses.rb (we haven’t created that either)
Let’s create those too.
So our require watir-webdriver statement lives here, we can remove it from step_karate.rb
Next, let’s add another file to the support subdirectory, called hooks.rb and use the Before and After methods to define actions that should be taken before and after each and every scenario. Like, starting up and closing down a browser.
Now we can remove those statements from step_karate.rb as well.
If we re-run the scenario this time, it will still fail but the browser will be closed down regardless of the outcome.
8. HTML Formatters
You can also direct cucumber output to an HTML file using the default HTML formatters. by running the command:
cucumber -f html >output.html
The contents of output.html then look like this:
So as you can see the failed step is highlighted in red, as is the scenario, as is the cucumber header (if one scenario out of many fail then the header is coloured red accordingly).
Now let’s change the string ‘Octavias’ back to ‘Ohtsuka’ and re-run
The Scenario headers in these HTML files can be collapsed or expanded individually (left click on it) or along with everything else in the page (use ‘Collapse All’/’Expand All’ in the header)
9. Multiple (Similar) Scenarios – Placeholders
So our scenario checks the presence of the karate founder’s surname in the results when we search for the style name. What if we wanted to run a similar scenario for other styles of karate, say:
- Wado-Ryu (Hironori Ohtsuka)
- Shotokan (Gichin Funakoshi)
- Goju-Ryu (Chojun Miyagi)
- Kyokushinkai (Masutatsu Oyama)
We could of course write separate scenarios and create new step definitions (primarily for steps 2 and 3, step 1 could be reused). The trouble there is that when you have a lot of scenarios which do the same thing with different arguments, it becomes laborious to wade through the results and difficult to see the uniqueness of each scenario.
So let’s consider refactoring our scenario to become a scenario outline – that way we only have to specify our steps once, and use placeholders to identify the unique values we wish to use within each iteration. Here’s what the refactored feature file looks like:
So the placeholders are the elements in the angled brackets in the steps, <karateStyle> and <masterSurname>. The Examples section (Note, you could also use the text ‘Scenarios:’ here instead of ‘Examples:’) is simply a table with the placeholder names (minus the angled brackets) as headers and the values you wish to use below them.
The scenario outline is useless without the examples and the four examples now constitute a single scenario.
Let’s take a look at the refactored step definition file:
The (\w+) elements are shorthand character classes and stand for a word character, specifically [A-Za-z0-9]. The value is read into the variable (karate or surname) which we can then use in place of the string literals (‘Wado’ and ‘Ohtsuka’) we had previously.
Tagging is easily one of the most powerful aspects of cucumber and for me, the thing that made it so versatile when dealing with a large number of scenarios. A tag in cucumber is simply a text string preceded by the ampersand character, and we generally use them in the feature file by placing them before Gherkin keywords such as Scenario Outline, Scenarios, Examples, etc. You can have more than one tag for the same scenario, just separate them with spaces.
Tags can represent anything that’s meaningful to you – the name of the scenarios (e.g. @scenario1, @scenario2, etc.) , the performance of the scenarios (e.g. @quick, @slow, @glacial), the frequency of the scenarios (e.g. @hourly, @daily, @weekly, etc.) – anything that makes it easier to slice and dice your scenarios into meaningful cross-sections that make execution a breeze.
Let’s refactor our feature file with some tags:
We can run cucumber and pass in some arguments to tell it to run everything associated with a particular tag by using a command like
where <tag> is the tag name. So in the case above if we ran:
- cucumber -t @all (This would run everything – all four scenarios)
- cucumber -t @daily (This would run the top two scenarios for Wado and Shotokan)
- cucumber -t @monthly (This would run the bottom two scenarios for Goju and Kyokushinkai)
- cucumber -t @wado (This would only run the top scenarios for Wado)
You get the idea, right?
So there you go, 10 steps to cukey heaven. Enjoy…
